Datasheet(CN) Datasheet(EN) PC-Gentec-EO User's Manual THZ-D User's Manual
Gentec-EO THZ12D-3S-VP-D0 THz detector for power measurements up to 3 W.
Key Features
Relative Measurements from 0.1 to 30 THz
Broadband, room temperature operation, easier to use and less expensive than a Golay cell
Flat Spectral Response
Get the best precision accross the entire wavelength range.
Measure Higher Powers
Up to 3 W of continuous power with the THZ12D model, the highest in our THz range of products
Large Aperture
Models range from 9 to 12 mm ? aperture.
Calibrated at 10.6 μm
THZ-D detectors are calibrated at a single wavelength (10.6 μm) and include wavelength correction data from 10.6 to 440 μm. They are used for relative measurements outside that range.
Specifications
| Measurement capabilities | |
| Maximum average power | 3 W |
| Noise equivalent power | 0.5 μW |
| Spectral range | 10 - 3000 μm |
| Frequency | 0.1 - 30 THz |
| Typical rise time | 3 s |
| Typical power sensitivity | 200 mV/W |
| Power calibration uncertainty | ±8.0 % |
| Repeatability | ±0.5 % |
| Thermal drift | 12 μW/°C |
| Minimum measurable power | 50 - 100 μW |
| Minimum repetition rate | 7 Hz |
| Damage thresholds | |
| Maximum average power density | 30 W/cm2 |
| Maximum energy density | 1 J/cm2 |
| Physical characteristics | |
| Aperture diameter | 12 mm |
| Absorber | VP |
| Dimensions | 73H x 73W x 20D mm (72D mm with tube) |
| Weight | 0.32 kg |
